Custom Dynamics Smart Triple Play Run Turn Brake Controller for Harley 14-15 BCM
This module triples your visibility in the rear.
SMART Triple Play® Features
- Converts Rear Turn Signals to Run-Brake-Turn
- Works with LEDs or Incandescent Bulbs
- Choice of 10 User Selectable Built In Brake Light Strobe/Flash Patterns (User can also select no Strobe/Flash on Brake)
Pattern 0: Four Flashes then Solid (Incandescent or LED)
Pattern 1: Four Flashes, Solid for 3 Seconds, Repeat (Incandescent or LED)
Pattern 2: Seven Flashes then Solid (Incandescent or LED)
Pattern 3: Seven Flashes, Solid for 3 Seconds, Repeat (Incandescent or LED)
Pattern 4: Quad Strobe, then Solid for 1 Second then Quad Strobe (LED Only)
Pattern 5: Quad Strobe, Solid for 1 Second, then Quad Strobe, Solid for 3 Seconds, Repeat (LED Only)
Pattern 6: Custom LED Blaster X Cycle for 3 seconds, then Solid (LED Only)
Pattern 7: Custom LED Blaster X Cycle, Repeat (LED Only)
Pattern 8: Max Strobe 4 Seconds, Solid (LED Only)
Pattern 9: Constant Max Strobe Pattern (LED Only)
- Ability to apply Brake Strobe/Flash Patterns on Center Taillight only, Rear Turns Only, or Rear Turns & Center Taillight
- SMART Function - If Brake Strobe/Flash is Turned On, Strobe/Flashing will be paused on Turn Signal if Simultaneous Braking and Turning
- 10 User Selectable Running Light Intensities Allow User to Match the Running Light Brightness of Turns to Center Taillight
- Built In Short Circuit Protection
- Sealed, Weather Tight Case
- Slim Line Design: 4.2" x 1.4" x 0.6"
- 5 Year Warranty
Important: For this system to be legal you must use RED single intensity rear turn signal lamps.
Important: This system is designed to work with single intensity rear turn signals, if you do not have single intensity rear turn signals do not install this module. Contact Technical Support.
- Power By
** The use of this product requires a Signal Stabilizer or Load Equalizer. ('11-present Softails and 12'-present Dynas, 14'-present Touring and Sportsters do NOT require a Signal Stabilizer or Load Equalizer)
If the bike is equipped with an alarm AND a Signal Stabilizer is not used, a Alarm Friendly Load Equalizer is Required. Custom Dynamics® recommends the use of a Signal Stabilizer over a Load Equalizer.
Fits: '14-15 Road King, '14-'15 CVO Limited, '15 CVO Road Glide Ultra
Brand | Custom Dynamics |
---|---|
Drag Part # | 2050-0197 |
Manufacturer Part No. | GEN-SMARTTPUBCM |
Fitment | 14-19 Road King, '14-'15 CVO Limited, '15 CVO Road Glide Ultra |
Ships Within: | 2-4 Days |
14-19 Road King, '14-'15 CVO Limited, '15 CVO Road Glide Ultra
5 Year Manufacturer's Warranty
